ZGH Series High-Speed Mixer
Key words：ZGH Series High-Speed Mixer
Description：DetailsZGH Series High-Speed Mixer1.Features: The structure of a horizontal cylinder, and a rational structure. Inflatable seal CV, cleaning can be switched into the water.Smooth operation,reliable performance,easy to operate.In the same closed contai…
Details
ZGH Series High-Speed Mixer
1.Features:
The structure of a horizontal cylinder, and a rational structure.
Inflatable seal CV, cleaning can be switched into the water.
Smooth operation,reliable performance,easy to operate.
In the same closed containers to be in line with GMP standards.
The whole operation with strict security measures of protection.
2. Constituent part:
This machine is consist of mainframe、cylinder、stirring system、cutting system、cylinder cover、discharge device、electrical control system、water system and so on. The process:1,put the raw material into the cylinder,then pour into the adhesive or liquid.2,put the raw material or other adhesive together into the cylinder: minxing and cutting by knife.
LCH
|
Name
|
200
|
350
|
500
|
600
|
1000
|
|
Capacity(L)
|
200
|
350
|
500
|
600
|
1000
|
|
Kg/batch
|
80
|
120
|
230
|
280
|
350
|
|
Mixing power (kw)
|
7.5
|
11
|
15
|
18.5
|
30
|
|
Cutting power (kw)
|
1.5
|
2.2
|
4
|
5.5
|
7.5
|
