Working Principle
The powder raw material and adhesive in a cylinder are fully mixed at the bottom to become a humid soft material. Then it is cut by high-speed cutter and become uniform granules .
Characteristics
◎The machine adopts horizontal cylinder structure, its structure reasonable;
◎Air lled seal shaft for to drive. When washing , it can be changed to water;
◎Fluidized Granulation, the granule is around ball shape. Its ow ability is good;
◎Compared to traditional process, 25% of adhesive can be reduced and the drying time is short;
◎The dry mixing time is 2 minutes and the granulating time is 1-4 minutes;
◎Compared to the traditional process , 4-5 times of ef ciency is raised;
◎Dry mixing ,humid mixing and granulating are nished in the same sealed container;
◎The whole operation has strict safe and protective measures;
◎Jacket type might be adopted on request.
Technical Parameter
| Type | A | B | C×D | E | F |
| 50 | 320 | 950 | 1250×800 | 970 | 1650 |
| 150 | 420 | 1000 | 1350×800 | 1050 | 1750 |
| 200 | 500 | 1100 | 1650×940 | 1450 | 2050 |
| 250 | 500 | 1160 | 1650×940 | 1400 | 2260 |
| 300 | 550 | 1200 | 1700×1000 | 1400 | 2310 |
| 400 | 670 | 1300 | 1860×1100 | 1550 | 2410 |
| 600 | 750 | 1500 | 2000×1230 | 1750 | 2610 |
| Name | Type | ||||||
| 50 | 150 | 200 | 250 | 300 | 400 | 600 | |
| Volume (L) | 50 | 150 | 200 | 250 | 300 | 400 | 600 |
| output capacity (kg/batch) | 15 | 50 | 80 | 100 | 130 | 200 | 280 |
| admix speed (r.p.m) | 200/400 | 180/270 | 180/270 | 180/270 | 140/220 | 106/155 | 80/120 |
| admix power (kw) | 4/5.5 | 6.5/8 | 9/11 | 9/11 | 13/16 | 18.5/22 | 22/30 |
| cutting speed (r.p.m) | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 |
| cutting power (kw) | 1.3/1.8 | 2.4/3 | 4.5/5.5 | 4.5/5.5 | 4.5/5.5 | 6.5/8 | 9/11 |
| compressed air consumption (m3/min) | 0.6 | 0.9 | 0.9 | 0.9 | 1.1 | 1.5 | 1.8 |
| weight (kg) | 500 | 800 | 1000 | 1300 | 1800 | 2200 | 2600 |
